Eayload-300 Reliable Cargo Winch for Drone Delivery
Electric Release System – Wireless control for precise mid-air cargo release.（Electric release hook only）
Anti-Twist Design – Prevents rope entanglement during operation.
One-Touch Cargo Release & Lift – Quick operation with ease of use.
Emergency Rope Cut-Off – Instantly severs the rope in critical situations.
Auto Hook Release upon Ground Contact – Automatically stops and releases the hook when touching down.（Electric release hook only）
Automatic Rope Management – Standard 30m cable with regulated winding.
Night Navigation Lights – Dual aviation lights for operation visibility.
Safe Stop at Top – Slows the ascent before reaching the top.
Upper & Lower Limit Stops – Automatically stops rope winding or unwinding at pre-set height limits.
Power Failure Braking – Automatically locks the winch to prevent unintended cargo drops.
Real-Time Tension Monitoring – Constantly tracks rope tension to ensure safe operation.
Swing Detection – Monitors rope sway, direction, and speed to optimize stability.
Eayload-300 is specialized lifting systems designed for helicopters and other heavy-lift aerial platforms. They support third-party control integration and customizable development, providing flexible, high-capacity solutions for demanding aerial transport and deployment missions.
Control Method: Protocol control only.
Key Features
Electric Release System – Wireless control for precise mid-air cargo release.（Electric release hook only）
Anti-Twist Design – Prevents rope entanglement during operation.
One-Touch Cargo Release & Lift – Quick operation with ease of use.
Emergency Rope Cut-Off – Instantly severs the rope in critical situations.
Auto Hook Release upon Ground Contact – Automatically stops and releases the hook when touching down.（Electric release hook only）
Automatic Rope Management – Standard 30m cable with regulated winding.
Night Navigation Lights – Dual aviation lights for operation visibility.
Safe Stop at Top – Slows the ascent before reaching the top.
Upper & Lower Limit Stops – Automatically stops rope winding or unwinding at pre-set height limits.
Power Failure Braking – Automatically locks the winch to prevent unintended cargo drops.
Real-Time Tension Monitoring – Constantly tracks rope tension to ensure safe operation.
Swing Detection – Monitors rope sway, direction, and speed to optimize stability.
Your Purchase Includes
1x Eayload-300 Main Unit
1x Payload Release Module(Electric Release Version)
1x Electric/Mechanical Release Hook
1x Upper Limit Trigger
1x User Manual
1x Certificate of Compliance
1x Battery Charger for Payload Module
2x Battery for Payload Module
1x Integrated Power & Communication Cable
6x M8X20 Hex Bolts
1x USB-To-RS232
1× Communication Antenna for Electric Hook and Winch Main Unit
Notes:
1. Do not use the fuse-cut function unless in an emergency. A dedicated fuse-cut test mode is available where the fuse wire is not heated; it only tests servo motor movement.
2. During actual heavy lifting tests, with the standard 30m rope, no more than 3 meters should remain inside the winch to prevent the load from being compressed onto the inner spool layers due to excessive weight.
3. To close the electric release hook properly, press the switch and wait for the servo activation sound before manually locking the hook.
4. During ground testing of the one-touch cargo release function, ensure the height is greater than 1.5 meters.
5. The outer shell has been upgraded to a high-strength molded housing for improved durability and wear resistance.
